Introduction
——————————
This system is controlled by motion controller, which can achieve the continuity of sealing for various size of insulating glass. It has two sets of independent sealant supplying system for double glazing/triple glazing insulating glass. It can produce double glazing and triple glazing, meanwhile it can seal the triple glass’s two space at one time.
The main feature
——————————
Technical parameters
——————————
| No. | Item |
| Max. glass size | 2000(L)×2580(W)mm |
| Min. glass size | 300(L)x300(W)mm |
| Glass thickness | 3-12mm |
| Insulating glass thickness | 12-56mm |
| Sealing width | 6-24mm |
| Sealing depth | 2-15mm |
| Sealing speed | 5-30m/min |
| Transmission speed | 0-48m/min |
| Hydraulic pressure | <100kg/cm² |
| Power supply | 11KW |
| Air supply | 0.5-0.8Mpa |
| working height | 520-580mm |
| Dimension | 8290(L)×3000(W)×2950(H)mm |
Electrical components
————————————
| Main No. | Name. | Brand | Country |
| 1. | Motion controller(MP2200) | YASKAWA | JAPAN |
| 2. | Servo motor(7series) | YASKAWA | JAPAN |
| 3 | Controls module(IRO2310) | YASKAWA | JAPAN |
| 4 | Transducer | SCHNEIDER | FRANCE |
| 5 | Photoelectric switch | AUTONICS | KOREA |
| 6 | Approach switch | AUTONICS | KOREA |
| 7 | Low-voltage component | SCHNEIDER | FRANCE |
| 8 | Touch screen | SCHNEIDER | FRANCE |
| 9 | Pilot-operated type proportional flood valve | JILI | TAIWAN |
| 10 | Precise adjust pressure valve(five pieces) | SMC | JAPAN |
| 11 | Single-way valve | KOMPASS | TAIWAN |
| 12 | Air treatment | AIRTAC | TAIWAN |
| 13 | Air solenoid valve | AIRTAC | TAIWAN |
| 14 | Air cylinder | AIRTAC | TAIWAN |
| 15 | Linear guide | HIWIN | TAIWAN |
